JM32142HT
High Torque© (HT) retention knob, CAT40; 5/8"-11, 45°, Coolant through; O-Ring(s) included; replaces JM32142
Retention Knob Information and Installation (PDF)
Retention Knob Installation Video
| Category: | Retention Knobs |
| Thread Size: | .625-11 |
| Angle: | 45 |
| Knob Diameter: | 0.588 |
| L1 Length: | 0.9880 |
| L2 Length: | 1.264 |
| Flange Thickness: | 0.124 |
| Hole Diameter: | 0.118 |
| Knob Side O-Ring: | ORM0190-00480NBR-70 |
| Neck Diameter: | 0.392 |
| Pilot Diameter: | 0.641 |
| Shoulder Diameter: | 0.904 |
| Wrench Flat Diameter: | 0.743 |
| Socket Part #: | RKW40 |
| Number: | JM32142HT |
| Solid Version: | JM32114HTHS, JM31114HTHS(4) - (4) Note difference in flange thickness size |
| Thread Side O-Ring: | S-15 |
| Country of Origin: | USA |
This knob is a replacement for the following parts:
| Manufacturer | Part Number |
| For Machines (see disclaimer)*: | Ntc, Okuma-Howa |
* Retention knobs are not interchangeable. Machines are only given as a reference, JMPP makes no guarantee this is the correct knob for your machine. Please call us at 1-800-322-7750 or email sales@jmperformanceproducts.com for knob identification help.
